RSL 616M

Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Availability:
in stock, ready to be shipped
Original price Rs. 10,500.00 - Original price Rs. 10,500.00
Original price
Rs. 10,500.00
Rs. 10,500.00 - Rs. 10,500.00
Current price Rs. 10,500.00

Order RSL 616M Online in India at a Best Price

Miniature Compression Load Cells (MCLCs) are a cutting-edge piece of equipment (RSL 616M). The RSL 616M model is most well-known for its ability to monitor weight, despite the fact that it is made of the best stainless steel materials and has the most modern features. The Miniature Compression Load cell is one of the most well-known load cells available on the market today.

This product is widely used by customers since it is capable of producing a precise result in an industrial application. Customers like this feature. RSL 616M is the model number for this device. Because of its great level of accuracy, this piece of equipment is quite popular. There are a variety of size and style choices available. There are many different models, with weights ranging from 50 kilograms to one ton. Stainless steel components are used in the construction of the equipment to guarantee its long-term reliability and durability.

  • It is straightforward to set up.
  • Designing a specific load cell to meet a specific need may be accomplished.
  • Because of its small size, it is very simple to hide from view.
  • Capacity varies from 50 to 1000 kg per minute depending on the model.
  • It is capable of offering protection against the elements up to IP65 standards.
  • The structure is made of hardened stainless steel.
Inquire via WhatsApp

Precision C2
Composition Error 0.05
Rated Output (mv/v) 3 ± 0.003
Non-Linearity (%FS) 0.05
Hysteresis (%FS) 0.05
Repeatability (%FS) 0.03
Creep (%FS/30min) 0.03
Zero Balance (%FS) ± 1%
Input Resistance (Ω) 390 ± 10
Output Resistance (Ω) 350 ± 2
Insulation Resistance(MΩ) ≥5000(100VDC)
Excitation Voltage (V) 5~12 (VDC)
Compensated temp. Range (°C) -10 to +40
Working Temp. Range (°C) -20 to +55
Temp. Effect on Zero (%FS/10°C) 0.05
Temp. Effect on Span (%FS/10°C) 0.05
Safe Overload (%FS) 150
Ultimate Overload (%FS) 200
Defend Grade IP67
Cable 4 Mtr 4 Core 4mm OD
